Parameters

(8-piece cutting fully functional type)
Input voltage: AC100-240V, 50/60Hz
Rated power: 600W
● Light source: LED module
LED lifespan: 30000 hours
Color temperature: 8000K
Color rendering index: standard mode Ra>75, high rendering mode Ra>90
● Luminous flux: 24000LM
● Power interface: 16A power plug, can be held in hand
● Signal interface: Three core XLR socket
Control mode: DMX512, RDM
Channel mode: 36 international standard DMX512 channels
Display system: 2.5-inch touch screen LCD display, displaying both Chinese and English, with a 180 degree rotation
Fixed colors: 9 colors+white light
● Color mixing system: independent CMY color mixing system
Color temperature adjustment: independent CTO2800-6000 K-line adjustment
Prism disk: 4 prisms can rotate independently
● Effect panel: Dazzling simulation of dynamic flames, flowing water and other dynamic effects
Fixed pattern: 9 fixed pattern pieces+white circles
● Rotating pattern: 5 glass pattern pieces (pluggable)
Cutting system: 8 independent cutting blades, each capable of individually closing the light,
Atomization system: 0-100% linear atomization
Aperture system: 5%~100% smooth adjustment
Four in one optical lens design: (BEAM beam mode): 2 ° to 6 °; (SPOT pattern mode): 10 ° to 48 °; (WASH staining mode): Four modes from 0 ° to 52 ° can be freely switched to achieve the four in one function of beam, staining, pattern, and cutting.
Dimming system: 0-100% linear adjustment
● Strobe system: The maximum frequency can reach 25Hz, and random flicker and pulse flicker can be selected
Horizontal scanning: 540 ° (16 bit precision scanning)
Vertical scanning: 270 ° (16 bit precision scanning)
● Protection level: IP20
Working environment: 0-45 ℃

Packaging size: 61 * 54 * 47cm
Gross weight: 18kg

Perfect Effect
